SPECIFICATION:

Rating: 3A 120V AC

SMD Type

Dielectric Strength: AC 1,000 V 1 Minute

Insulation Resistance: 1,000 MΩ Mim

Contact Resistance: 20MΩ Max.

Operating Temperature: -30oC ~ +85oC

FUNCTION:

S = SPDT

□ = S1: on-on

     = S2: on-(on)

     = S3: on-off-on

     = S5: on-off-(on)

(  ) = Momentary

Approvals : RoHS,UL
