SPECIFICATION:

Rating: 0.3A 30V DC

Circuit: 1P2T 3PIN

Travel: 2mm , Non Shorting

Operating Force: 250 ± 100g

Knob Length: 2.0 & 1.7mm

Dielectric Strength: AC 500 V 1 Minute

Insulation Resistance: 100 MΩ Mim. 500V DC

Contact Resistance: 70MΩ

Operating Temperature: -25oC ~ +70oC

Mechanical Life: 10,000 Cycles

Electrical Life: 10,000 Cycles
