SPECIFICATION:
Rating: 50mA 12V DC
SIZE: 6.0 x 6.0 x 7.3 mm
Operating force: 160gf , 250gf
Dielectric strength: AC 250 V 1 minute
Insulation resistance: 100 MΩ DC 250 V
Contact resistance: 100 MΩ Min.
Mechanical Life: 100,000 Cycles
Electrical Life: 100,000 Cycles
Operating Temperature: -20oC ~ +70oC
Approvals: RoHS
