General Specifications
Current Rating: 50mA
Voltage Rating: 12VDC
Dielectric Withstanding Voltage:250VAC for 1 minute
Contact Resistance: 100m Ohm Max.(initial)
Insulation Resistance: 100M Ohm Min.
Operating Force: 200gf ± 50gf
Total Travel: 0.25mm ± 0.1mm
Operating Life: 100,000 cycles Min.
Solder Specifications: 260 deg. for 3 seconds
Function Operating: SP5T
Temperature: -10 deg.~+60 deg.
