SPECIFICATION:
Rating: 15A 125V AC / 10A 250V AC
20A 125V AC / 16A 250V AC
Mounting Hole: 30.0 x 11.0 mm
Function: ON - OFF with Lamp
Terminal Type: #250 Terminal (6.3mm)
Insulation Resistance: 1,000 MΩ Mim. 500V DC
Contact Resistance: 20MΩ Max.
Withatand Voltage: AC 1,500 V 1 Minute
Mechanical Life: 30,000 Cycles
Electrical Life: 10,000 Cycles
Approvals : RoHS,UL,ENEC10,VDE,CQC
