SPECIFICATION:
Rating: 50mA 12V DC
Operating force: 160gf , 250gf
Dielectric strength: AC 250 V 1 minute
Insulation resistance: 100 MΩ DC 250 V
Contact resistance: 100 MΩ Min.
Mechanical Life: 100,000 Cycles
Electrical Life: 100,000 Cycles
Operating Temperature: -20oC ~ +70oC
Function:
□ = L (mm)
1 = 3.15 mm 5-1 = 6.85 mm 8-1 = 10.85 mm
2 = 3.85 mm 6 = 6.15 mm 9 = 15.85 mm
3 = 5.85 mm 7 = 11.35 mm
4 = 8.35 mm 8 = 11.85 mm
Approvals: RoHS
