SPECIFICATION:
Rating: 10A 125V / 6A 250V AC
Mounting Hole: 22 x 19 mm
Operation Force: 800 ± 300g
Function: ON - OFF
Terminal Type: Right Angle PCB Type
Insulation Resistance: 100 MΩ Mim. 500V DC
Contact Resistance: 30MΩ Max.
Withatand Voltage: AC 1,000 V 1 Minute
Electrical Life: 10,000 cycles
Operating Temperature: -25℃ ~ +85℃
Approvals : RoHS,UL,CSA,VDE,ENEC10
