SPECIFICATION:

Rating: 5A 125/250V AC

SIZE: 19.8 x 10.6 x 6.4mm

Operating Force: 115g

Terminal: Solder Type (3.2mm)

Withatand Voltage: AC 1,000 V 1 Minute

Insulation Resistance: 100 MΩ Mim. 500V DC

Contact Resistance: 50MΩ

Operating Temperature: -25oC ~ +85oC

Mechanical Life: 1,000,000 Cycles

Electrical Life: 10,000 Cycles
